ghidra::IfaceDecompCommand Class Reference

Root class for all decompiler specific commands. More...

#include <ifacedecomp.hh>

Inheritance diagram for ghidra::IfaceDecompCommand:

Public Member Functions
virtual void	setData (IfaceStatus *root, IfaceData *data)
	Associate a specific data object with this command.
virtual string	getModule (void) const
	Get the formal module name to which this command belongs.
virtual IfaceData *	createData (void)
	Create a specialized data object for this command (and its module)
virtual void	iterationCallback (Funcdata *fd)
	Perform the per-function aspect of this command.
void	iterateFunctionsAddrOrder (void)
	Iterate command over all functions in all scopes.
void	iterateFunctionsLeafOrder (void)
	Iterate command over all functions in a call-graph traversal.
Public Member Functions inherited from ghidra::IfaceCommand
virtual	~IfaceCommand (void)
	Destructor.
virtual void	execute (istream &s)=0
void	addWord (const string &temp)
	Add a token to the command line string associated with this command.
void	removeWord (void)
	Remove the last token from the associated command line string.
const string &	getCommandWord (int4 i) const
	Get the i-th command token.
void	addWords (const vector< string > &wordlist)
	Add words to the associated command line string.
int4	numWords (void) const
	Return the number of tokens in the command line string.
void	commandString (string &res) const
	Get the complete command line string.
int4	compare (const IfaceCommand &op2) const
	Order two commands by their command line strings.

Protected Member Functions
void	iterateScopesRecursive (Scope *scope)
	Iterate recursively over all functions in given scope.
void	iterateFunctionsAddrOrder (Scope *scope)
	Iterate over all functions in a given scope.

Protected Attributes
IfaceStatus *	status
	The console owning this command.
IfaceDecompData *	dcp
	Data common to decompiler commands.

Detailed Description

Root class for all decompiler specific commands.

Commands share the data object IfaceDecompData and are capable of iterating over all functions in the program/architecture.

Member Function Documentation

createData()

virtual IfaceData * ghidra::IfaceDecompCommand::createData ( void  )

inlinevirtual

Create a specialized data object for this command (and its module)

This method is only called once per module

Returns

the newly created data object for the module

Implements ghidra::IfaceCommand.

getModule()

virtual string ghidra::IfaceDecompCommand::getModule ( void  ) const

inlinevirtual

Get the formal module name to which this command belongs.

Commands in the same module share data through their registered IfaceData object

Returns

the formal module name

Implements ghidra::IfaceCommand.

iterateFunctionsAddrOrder() [1/2]

void ghidra::IfaceDecompCommand::iterateFunctionsAddrOrder ( Scope *  scope )

protected

Iterate over all functions in a given scope.

Runs over every function in the scope calling iterationCallback().

Parameters

scope

is the given scope

References ghidra::Scope::begin(), ghidra::Scope::end(), ghidra::FunctionSymbol::getFunction(), and iterationCallback().

iterateFunctionsAddrOrder() [2/2]

void ghidra::IfaceDecompCommand::iterateFunctionsAddrOrder

(

void

)

Iterate command over all functions in all scopes.

Scopes are traversed depth-first, then within a scope, functions are traversed in address order.

References ghidra::IfaceDecompData::conf, dcp, ghidra::Database::getGlobalScope(), iterateScopesRecursive(), and ghidra::Architecture::symboltab.

Referenced by ghidra::IfcSaveAllSignatures::execute(), ghidra::IfcProduceC::execute(), ghidra::IfcPrintInputsAll::execute(), ghidra::IfcDuplicateHash::execute(), ghidra::IfcCallGraphBuild::execute(), ghidra::IfcCallGraphBuildQuick::execute(), and iterateScopesRecursive().

iterateFunctionsLeafOrder()

void ghidra::IfaceDecompCommand::iterateFunctionsLeafOrder

(

void

)

Iterate command over all functions in a call-graph traversal.

Traversal is based on the current CallGraph for the program. Child functions are traversed before their parents.

References ghidra::IfaceDecompData::cgraph, ghidra::IfaceDecompData::conf, dcp, and iterationCallback().

Referenced by ghidra::IfcProducePrototypes::execute(), and ghidra::IfcCallGraphList::execute().

iterateScopesRecursive()

void ghidra::IfaceDecompCommand::iterateScopesRecursive ( Scope *  scope )

protected

Iterate recursively over all functions in given scope.

Runs over every function in the scope, or any sub-scope , calling iterationCallback()

Parameters

scope

is the given scope

References ghidra::Scope::childrenBegin(), ghidra::Scope::childrenEnd(), ghidra::Scope::isGlobal(), iterateFunctionsAddrOrder(), and iterateScopesRecursive().

Referenced by iterateFunctionsAddrOrder(), and iterateScopesRecursive().

iterationCallback()

virtual void ghidra::IfaceDecompCommand::iterationCallback ( Funcdata *  fd )

inlinevirtual

Perform the per-function aspect of this command.

Parameters

fd	is the particular function to operate on

Reimplemented in ghidra::IfcSaveAllSignatures, ghidra::IfcProduceSignatures, ghidra::IfcProduceC, ghidra::IfcProducePrototypes, ghidra::IfcPrintInputsAll, ghidra::IfcDuplicateHash, ghidra::IfcCallGraphBuild, and ghidra::IfcCallGraphList.

Referenced by iterateFunctionsAddrOrder(), and iterateFunctionsLeafOrder().

setData()

virtual void ghidra::IfaceDecompCommand::setData ( IfaceStatus *  root, IfaceData *  data  )

inlinevirtual

Associate a specific data object with this command.

Parameters

root	is the interface object this command is registered with
data	is the data object the command should use

Implements ghidra::IfaceCommand.

References dcp, and status.

---

The documentation for this class was generated from the following files:

• ifacedecomp.hh
• ifacedecomp.cc
